Industrial lift with an operator on board model TREZ TC-O
The TC-O is a freight lift that is safe for people to carry in accordance with European safety standards. If fitted with a cabin and an automatic cabin door, users will not distinguish it from a passenger and cargo elevator. It is designed to comply with the Machinery Directive, which gives more freedom to the TREZ design engineers, so TC-O becomes quieter, with less power, and can be erected directly on the ground floor.
TC-O vs Passanger and freigh elevator | ||
Model lift | TC-O | Passenger and freigh elevator |
Max safe load | 1000 kg | 1000 kg |
Standard/Directive | Machinery Directive 2006/42/EC | Passanger Lifts Directive 2014/33/EU |
Main drive | Hydraulic | Hydraulic |
Motor power | 4 kW | 12 kW |
Speed | 0,2 m/s | 0,5 m/s |
Travel 6 meters (3 levels) | 44 seconds | 18 seconds |
Minimum pit | 120 mm or ramp | 1100 mm |
Minimum headroom | 2600 mm | 3400 mm |
Cabin for the lift | option | standard |
Landing doors | standard | standard |
Cabin doors | option | standard |
A forklift can enter the lift on the Ground level . | standard | forbiden |
Control | Industrial PLC | Motherboard for passenger elevators. |
Automatic releveling for the floor levels | +- 3 mm | +- 20 mm |
