Goods only lift model TREZ TC

The hydraulic goods-only lift-brand TC (Trez Compact) is the company's top product. The latest, 3rd generation is made from hot-dipped galvanized steel and stainless steel fasteners. For all the lifts TC there is no need to dig a pit: it can be installed directly on the finished floor. The maximum safe load starts at 300 kg and goes up to 6000 kg. The usable space is up to 3600x5400 mm. The TC is suitable for work in warehouses, factories, shops and storage units. It can be installed indoors or outdoors. The start configuration is a flat deck platform with hold-to-run operation. The highest equipment level is a fully closed cargo cabin with industrial cargo doors for the floors and push-to-go operation.

  Maximum lift size vs MSL (Maximum Safe Load )
  0,7 0,8 0,9 1 m 1,1 1,2 1,3 1,4 1,5 1,6 1,8 1,9 2 2,2 2,4 2,6 2,8 3 m 3,3 3,5 4 m 4,5 5 m 5,4
0,3 t
0,5 t           TC
1 t
1,5 t
2 t
3 t                                         TC 2C
4 t                                                                                                 TC 4C
5 t
6 t
